Name: China Disabled Passenger Lift Manufacturers, Suppliers and Factory - Custom Service - Weibo Elevator
Brand: Webstar
SKU: 296884222

Webstar is an elevator manufacturer specializing in manufacturing and research and development. If you are interested in the elevator for disabled passengers, you can contact us at any time to discuss the details.

Send Inquiry

Product Introduction

Product Details

Disabled passenger lift are not only used for transporting passengers but also have special and strict requirements for their functional performance due to their unique usage. Webstar's disabled passenger lift can precisely control the elevator's running speed and operates smoothly and comfortably. Elevators emphasize humanized design to fully optimize the structure of the car and meet the usage requirements of customers to the greatest extent. Create a peaceful and elegant space for passengers.

Advantages

Disabled passenger lifts ensure normal passage, safety, reliability and a stress-free experience for users. They also have value beyond compliance for building owners and managers, expanding the service scope of elevators and enhancing the image of buildings. This reflects Webstar's emphasis on diverse groups of people and also demonstrates its own "customization capability". This elevator can be effectively applied in all scenarios such as public buildings, transportation hubs, hospitals and high-end residences.

36dd0fa4-3bed-42fc-8412-06cbb72a52a2

Precise matching of accessibility needs

The cabin is large in size to ensure the normal passage of people. The main opening methods are central or side-opening automatic doors, with a clear opening width of more than 0.8 meters. The reasonable dimensions of the sedan and the door facilitate the entry and direction adjustment of the wheelchair, and also make it convenient for the accompanying personnel.

The cabin is equipped with a two-way operation panel, which can ensure convenient operation for personnel. The panel buttons are equipped with Braille and numbers, and the panel height is reasonable, providing necessary assistance to those in need.

The cabin provides voice announcements, indicating the running direction and the floor to be reached. Clear floor displays are provided both inside and outside the cabin. Provide convenient prompts for those in need through vision and hearing.

The cabin can be equipped with handrails on multiple sides to provide effective body support and anti-collision protection. The alarm device and the five-party communication function can be used to seek external assistance in special or emergency situations. Door protection is to extend the closing time under the effect of the light curtain to prevent passengers from being pinched. The elevator can be equipped with ARD, allowing the rechargeable battery to provide power to the elevator when the normal power supply is cut off, and the elevator will move to the nearest floor.

fbce50e4-db79-4869-8e45-fa07ea1a5022

Specification

WEBSTAR WP &WPN series passenger elevator
Machine room	MR/ MRL
Speed	1.0m/s,1.5m/s,1.75m/s,2.0m/s,2.5m/s,4.0m/s,6.0m/s
Load capacity	400kg,450kg,630kg,800kg,1000kg,1150kg,1250kg,1350kg,1600kg,2000kg
Travel height	3.2m - 125m
Drive type	VVVF
control system	Monarch
Traction machine	Gearless
Cabin size	According to the shaft size

Machine Roomless Elevator

product-941-1059

Main specifications
Loading capacity(kg)	Rated speed(m/s)	Car size(mm)			Door opening size(mm)			Shaft size(mm)		Counterweight position	Max. travelling height(m)	Pit depth (mm)	Top floor height(mm)	Roping
Loading capacity(kg)	Rated speed(m/s)	Width	Depth	Height	Width	Height	Mode	Width	Depth	Counterweight position	Max. travelling height(m)	Pit depth (mm)	Top floor height(mm)	Roping
450	1	1000	1100	2400	700	2100	CO	1850	1700	Left	50	1500	4100	2:1
450	1.5	1000	1100	2400	700	2100	CO	1850	1700	Left	75	1600	4300	2:1
630	1	1100	1400	2400	800	2100	CO	2000	1850	Left	50	1500	4100	2:1
	1.5	1100	1400	2400	800	2100	CO	2000	1850	Left	75	1600	4300	2:1
	1.75	1100	1400	2400	800	2100	CO	2000	1850	Left	90	1700	4500	2:1
800	1	1400	1350	2400	800	2100	CO	2200	1800	Left	50	1500	4100	2:1
	1.5	1400	1350	2400	800	2100	CO	2200	1800	Left	75	1600	4300	2:1
	1.75	1400	1350	2400	800	2100	CO	2200	1800	Left	90	1700	4500	2:1
	2	1400	1350	2400	800	2100	CO	2200	1800	Left	100	1800	4600	2:1
	2.5	1400	1350	2400	800	2100	CO	2200	1800	Left	125	1900	4800	2:1
1000	1	1600	1400	2400	900	2100	CO	2450	1900	Left	50	1500	4100	2:1
	1.5	1600	1400	2400	900	2100	CO	2450	1900	Left	75	1600	4300	2:1
	1.75	1600	1400	2400	900	2100	CO	2450	1900	Left	90	1700	4500	2:1
	2	1600	1400	2400	900	2100	CO	2450	1900	Left	100	1800	4600	2:1
	2.5	1600	1400	2400	900	2100	CO	2450	1900	Left	125	1900	4800	2:1
1150	1	1500	1700	2400	1000	2100	CO	2400	2100	Left	50	1500	4100	2:1
	1.5	1500	1700	2400	1000	2100	CO	2400	2100	Left	75	1600	4300	2:1
	1.75	1500	1700	2400	1000	2100	CO	2400	2100	Left	50	1700	4500	2:1
	2	1500	1700	2400	1000	2100	CO	2400	2100	Left	125	1800	4600	2:1
	2.5	1500	1700	2400	1000	2100	CO	2400	2100	Left	75	1900	4800	2:1
1250	1	1500	1900	2400	1000	2100	CO	2400	2350	Left	50	1500	4100	2:1
	1.5	1500	1900	2400	1000	2100	CO	2400	2350	Left	75	1600	4300	2:1
	1.75	1500	1900	2400	1000	2100	CO	2400	2350	Left	50	1700	4500	2:1
	2	1500	1900	2400	1000	2100	CO	2400	2350	Left	125	1800	4600	2:1
	2.5	1500	1900	2400	1000	2100	CO	2400	2350	Left	75	1900	4800	2:1
1350	1	1950	1500	2400	1000	2100	CO	2900	2100	Left	125	1500	4100	2:1
	1.5	1950	1500	2400	1000	2100	CO	2900	2100	Left	125	1600	4300	2:1
	1.75	1950	1500	2400	1000	2100	CO	2900	2100	Left	125	1700	4500	2:1
	2	1950	1500	2400	1000	2100	CO	2900	2100	Left	50	1800	4600	2:1
	2.5	1950	1500	2400	1000	2100	CO	2900	2100	Left	75	1900	4800	2:1
1600	1	1950	1700	2400	1000	2100	CO	2900	2400	Left	90	1500	4100	2:1
	1.5	1950	1700	2400	1000	2100	CO	2900	2400	Left	100	1600	4300	2:1
	1.75	1950	1700	2400	1000	2100	CO	2900	2400	Left	125	1700	4500	2:1
	2	1950	1700	2400	1000	2100	CO	2900	2400	Left	125	1800	4600	2:1
	2.5	1950	1700	2400	1000	2100	CO	2900	2400	Left	125	1900	4800	2:1

Machine Room Elevator

product-941-1059

Main specifications
Loading capacity(kg)	Rated speed(m/s)	Car size(mm)			Door opening size(mm)			Shaft size(mm)		Counterweight position	Max. travelling height(m)	Pit depth (mm)	Top floor height(mm)	Roping
Loading capacity(kg)	Rated speed(m/s)	Width	Depth	Height	Width	Height	Mode	Width	Depth	Counterweight position	Max. travelling height(m)	Pit depth (mm)	Top floor height(mm)	Roping
450	1	1100	1000	2400	700	2100	CO	1700	1650	Rear	50	1500	4500	2:1
450	1.5	1100	1000	2400	700	2100	CO	1700	1650	Rear	75	1600	4600	2:1
630	1	1400	1100	2400	800	2100	CO	2000	1750	Rear	50	1500	4500	2:1
	1.5	1400	1100	2400	800	2100	CO	2000	1750	Rear	75	1600	4600	2:1
	1.75	1400	1100	2400	800	2100	CO	2000	1750	Rear	90	1700	4700	2:1
800	1	1400	1350	2400	800	2100	CO	2000	2000	Rear	50	1500	4500	2:1
	1.5	1400	1350	2400	800	2100	CO	2000	2000	Rear	75	1600	4600	2:1
	1.75	1400	1350	2400	800	2100	CO	2000	2000	Rear	90	1700	4700	2:1
	2	1400	1350	2400	800	2100	CO	2000	2000	Rear	100	1800	4800	2:1
	2.5	1400	1350	2400	800	2100	CO	2000	2000	Rear	125	1900	5100	2:1
1000	1	1600	1400	2400	900	2100	CO	2200	2050	Rear	50	1500	4500	2:1
	1.5	1600	1400	2400	900	2100	CO	2200	2050	Rear	75	1600	4600	2:1
	1.75	1600	1400	2400	900	2100	CO	2200	2050	Rear	90	1700	4700	2:1
	2	1600	1400	2400	900	2100	CO	2200	2050	Rear	100	1800	4800	2:1
	2.5	1600	1400	2400	900	2100	CO	2200	2050	Rear	125	1900	5100	2:1
1150	1	1700	1500	2400	1000	2100	CO	2300	2150	Rear	50	1500	4500	2:1
	1.5	1700	1500	2400	1000	2100	CO	2300	2150	Rear	75	1600	4600	2:1
	1.75	1700	1500	2400	1000	2100	CO	2300	2150	Rear	90	1700	4700	2:1
	2	1700	1500	2400	1000	2100	CO	2300	2150	Rear	100	1800	4800	2:1
	2.5	1700	1500	2400	1000	2100	CO	2300	2150	Rear	125	1900	5100	2:1
1250	1	1950	1400	2400	1000	2100	CO	2600	2100	Rear	50	1500	4500	2:1
	1.5	1950	1400	2400	1000	2100	CO	2600	2100	Rear	75	1600	4600	2:1
	1.75	1950	1400	2400	1000	2100	CO	2600	2100	Rear	90	1700	4700	2:1
	2	1950	1400	2400	1000	2100	CO	2600	2100	Rear	100	1800	4800	2:1
	2.5	1950	1400	2400	1000	2100	CO	2600	2100	Rear	125	1900	5100	2:1
1350	1	1950	1500	2400	1000	2100	CO	2600	2300	Rear	50	1500	4500	2:1
	1.5	1950	1500	2400	1000	2100	CO	2600	2300	Rear	75	1600	4600	2:1
	1.75	1950	1500	2400	1000	2100	CO	2600	2300	Rear	90	1700	4700	2:1
	2	1950	1500	2400	1000	2100	CO	2600	2300	Rear	100	1800	4800	2:1
	2.5	1950	1750	2400	1000	2100	CO	2600	2300	Rear	125	1900	5100	2:1
1600	1	1950	1750	2400	1000	2100	CO	2600	2550	Rear	50	1500	4500	2:1
	1.5	1950	1750	2400	1000	2100	CO	2600	2550	Rear	75	1600	4600	2:1
	1.75	1950	1750	2400	1000	2100	CO	2600	2550	Rear	90	1700	4700	2:1
	2	1950	1750	2400	1000	2100	CO	2600	2550	Rear	100	1800	4800	2:1
	2.5	1950	1750	2400	1000	2100	CO	2600	2550	Rear	125	1900	5100	2:1
